Implements a WebSocket client over an HTTP connection. Supports both synchronous and asynchronous operations. More...
Public Member Functions | |
| WsClient(string address, int port, TcpClientOptions options) override bool | Connect () |
| Initializes a new instance of the WsClient class. | |
| override bool | ConnectAsync () |
| Establishes an asynchronous connection to the WebSocket server. | |
| int | SendText (byte[] buffer) |
| Sends a text message synchronously to the server. | |
| int | SendText (byte[] buffer, int position, int length) |
| Sends a text message synchronously to the server. | |
| bool | SendTextAsync (byte[] buffer) |
| Sends a text message asynchronously to the server. | |
| bool | SendTextAsync (byte[] buffer, int position, int length) |
| Sends a text message asynchronously to the server. | |
| int | SendBinary (byte[] buffer) |
| Sends a binary message synchronously to the server. | |
| int | SendBinary (byte[] buffer, int position, int length) |
| Sends a binary message synchronously to the server. | |
| bool | SendBinaryAsync (byte[] buffer) |
| Sends a binary message asynchronously to the server. | |
| bool | SendBinaryAsync (byte[] buffer, int position, int length) |
| Sends a binary message asynchronously to the server. | |
| int | SendClose (int status, byte[] buffer) |
| Sends a close frame with a status code synchronously to the server. | |
| int | SendClose (int status, byte[] buffer, int position, int length) |
| Sends a close frame with a status code synchronously to the server. | |
| bool | SendCloseAsync (int status, byte[] buffer) |
| Sends a close frame with a status code asynchronously to the server. | |
| bool | SendCloseAsync (int status, byte[] buffer, int position, int length) |
| Sends a close frame with a status code asynchronously to the server. | |
| int | SendPing (byte[] buffer) |
| Sends a ping frame synchronously to the server. | |
| int | SendPing (byte[] buffer, int position, int length) |
| Sends a ping frame synchronously to the server. | |
| bool | SendPingAsync (byte[] buffer) |
| Sends a ping frame asynchronously to the server. | |
| bool | SendPingAsync (byte[] buffer, int position, int length) |
| Sends a ping frame asynchronously to the server. | |
| int | SendPong (byte[] buffer) |
| Sends a pong frame synchronously to the server. | |
| int | SendPong (byte[] buffer, int position, int length) |
| Sends a pong frame synchronously to the server. | |
| bool | SendPongAsync (byte[] buffer) |
| Sends a pong frame asynchronously to the server. | |
| bool | SendPongAsync (byte[] buffer, int position, int length) |
| Sends a pong frame asynchronously to the server. | |
| virtual void | OnWsConnecting (HttpRequest request) |
| Prepares the WebSocket connection by setting the necessary headers. | |
| virtual void | OnWsConnected (HttpResponse response) |
| Called when the WebSocket connection is successfully established. | |
| virtual void | OnWsConnected (HttpRequest request) |
| Called when the WebSocket connection is successfully established. | |
| virtual bool | OnWsConnecting (HttpRequest request, HttpResponse response) |
| OnWsConnecting. | |
| virtual void | OnWsDisconnecting () |
| Called when the WebSocket connection is in the process of disconnecting. | |
| virtual void | OnWsDisconnected () |
| Called when the WebSocket connection is successfully disconnected. | |
| virtual void | OnWsReceived (byte[] buffer, int position, int length) |
| Processes the WebSocket frames received from the server. | |
| virtual void | OnWsClose (byte[] buffer, int position, int length, int status=1000) |
| Handles a close frame received from the server. | |
| virtual void | OnWsPing (byte[] buffer, int position, int length) |
| Handles a ping frame received from the server by sending a pong frame. | |
| virtual void | OnWsPong (byte[] buffer, int position, int length) |
| Handles a pong frame received from the server. | |
| virtual void | OnWsError (string error) |
| Handles a WebSocket error by reporting it to the client. | |
| virtual void | OnWsError (SocketError error) |
| Handles a WebSocket error by reporting it to the client. | |
| void | SendUpgrade (HttpResponse response) |
| Upgrades the HTTP connection to a WebSocket connection. | |
Public Member Functions inherited from XmobiTea.ProtonNetClient.HttpClient | |
| HttpClient (string address, int port, TcpClientOptions options) | |
| Initializes a new instance of the HttpClient class. | |
| int | SendRequest (HttpRequest request) |
| Sends an HTTP request synchronously using the provided request data. | |
| bool | SendRequestAsync (HttpRequest request) |
| Sends an HTTP request asynchronously using the provided request data. | |
Public Member Functions inherited from XmobiTea.ProtonNetClient.TcpClient | |
| TcpClient (string address, int port, TcpClientOptions options) | |
| Initializes a new instance of the TcpClient class. | |
| INetworkStatistics | GetNetworkStatistics () |
| Gets the network statistics associated with the client. | |
| virtual bool | Disconnect () |
| Disconnects the client from the server synchronously. | |
| virtual bool | Reconnect () |
| Reconnects the client to the server by first disconnecting and then reconnecting. | |
| virtual bool | DisconnectAsync () |
| Disconnects the client from the server asynchronously. | |
| virtual bool | ReconnectAsync () |
| Reconnects the client to the server asynchronously by first disconnecting and then reconnecting. | |
| virtual int | Send (byte[] buffer) |
| Sends data to the server synchronously. | |
| virtual int | Send (byte[] buffer, int position, int length) |
| Sends data to the server synchronously starting from a specific position in the buffer. | |
| virtual bool | SendAsync (byte[] buffer) |
| Sends data to the server asynchronously. | |
| virtual bool | SendAsync (byte[] buffer, int position, int length) |
| Sends data to the server asynchronously starting from a specific position in the buffer. | |
| void | Dispose () |
| Disposes the TCP client, releasing all resources. | |
Public Member Functions inherited from XmobiTea.ProtonNetClient.IClient | |
Public Member Functions inherited from XmobiTea.ProtonNetClient.IHttpClient | |
Public Member Functions inherited from XmobiTea.ProtonNetCommon.IWebSocket | |
Public Member Functions inherited from XmobiTea.ProtonNetClient.IWsClient | |
Protected Member Functions | |
| override void | OnConnected () |
| Called when the client has successfully connected to the server. | |
| override void | OnDisconnecting () |
| Called when the client is in the process of disconnecting. | |
| override void | OnDisconnected () |
| Called when the client has successfully disconnected from the server. | |
| override void | OnReceived (byte[] buffer, int position, int length) |
| Processes the data received from the server. | |
| override void | OnReceivedResponseHeader (HttpResponse response) |
| Processes the response header received from the server. | |
| override void | OnReceivedResponse (HttpResponse response) |
| Processes the response body received from the server. | |
| override void | OnReceivedResponseError (HttpResponse response, string error) |
| Handles errors in the response received from the server. | |
Protected Member Functions inherited from XmobiTea.ProtonNetClient.HttpClient | |
Protected Member Functions inherited from XmobiTea.ProtonNetClient.TcpClient | |
| virtual void | OnConnecting () |
| Called when the client is in the process of connecting. Can be overridden in derived classes to handle the event. | |
| virtual void | OnSent (int sent, int pending) |
| Called when data is successfully sent to the server. Can be overridden in derived classes to handle the event. | |
| virtual void | OnEmpty () |
| Called when the send buffer is empty. Can be overridden in derived classes to handle the event. | |
| virtual void | OnError (SocketError error) |
| Called when an error occurs during socket operations. Can be overridden in derived classes to handle the event. | |
| virtual void | Dispose (bool disposingManagedResources) |
| Disposes the TCP client, releasing managed resources if specified. | |
Additional Inherited Members | |
Properties inherited from XmobiTea.ProtonNetClient.HttpClient | |
| HttpRequest | Request [get] |
| Gets the current HTTP request being processed by the client. | |
| HttpResponse | Response [get] |
| Gets the current HTTP response received from the server. | |
Properties inherited from XmobiTea.ProtonNetClient.TcpClient | |
| string | Id [get] |
| Gets the unique identifier for this TCP client instance. | |
| string | Address [get] |
| Gets the server address to which the client is connected. | |
| int | Port [get] |
| Gets the port number on the server to which the client is connected. | |
| EndPoint | EndPoint [get] |
| Gets the endpoint representing the server's address and port. | |
| Socket | Socket [get] |
| Gets the underlying socket used for the connection. | |
| TcpClientOptions | Options [get] |
| Gets the options used to configure the TCP client. | |
| bool | IsConnecting [get] |
| Gets a value indicating whether the client is currently connecting. | |
| bool | IsConnected [get] |
| Gets a value indicating whether the client is connected to the server. | |
| bool | IsDisposed [get] |
| Gets a value indicating whether the client has been disposed. | |
| bool | IsSocketDisposed [get] |
| Gets a value indicating whether the socket has been disposed. | |
Implements a WebSocket client over an HTTP connection. Supports both synchronous and asynchronous operations.
|
virtual |
Initializes a new instance of the WsClient class.
| address | The server address to connect to. |
| port | The port number on the server. |
| options | TCP client options for configuring the connection. |
Establishes a synchronous connection to the WebSocket server.
Reimplemented from XmobiTea.ProtonNetClient.TcpClient.
|
virtual |
Establishes an asynchronous connection to the WebSocket server.
Reimplemented from XmobiTea.ProtonNetClient.TcpClient.
|
protectedvirtual |
Called when the client has successfully connected to the server.
Reimplemented from XmobiTea.ProtonNetClient.TcpClient.
|
protectedvirtual |
Called when the client has successfully disconnected from the server.
Reimplemented from XmobiTea.ProtonNetClient.HttpClient.
|
protectedvirtual |
Called when the client is in the process of disconnecting.
Reimplemented from XmobiTea.ProtonNetClient.TcpClient.
|
protectedvirtual |
Processes the data received from the server.
| buffer | The buffer containing the received data. |
| position | The starting position in the buffer. |
| length | The length of the received data. |
Reimplemented from XmobiTea.ProtonNetClient.HttpClient.
|
protectedvirtual |
Processes the response body received from the server.
| response | The HTTP response received. |
Reimplemented from XmobiTea.ProtonNetClient.HttpClient.
|
protectedvirtual |
Handles errors in the response received from the server.
| response | The HTTP response that caused the error. |
| error | The error message. |
Reimplemented from XmobiTea.ProtonNetClient.HttpClient.
|
protectedvirtual |
Processes the response header received from the server.
| response | The HTTP response received. |
Reimplemented from XmobiTea.ProtonNetClient.HttpClient.
|
virtual |
Handles a close frame received from the server.
| buffer | The buffer containing the close frame. |
| position | The starting position in the buffer. |
| length | The length of the close frame. |
| status | The close status code. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
Called when the WebSocket connection is successfully established.
| request | The HTTP request that initiated the WebSocket connection. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
Called when the WebSocket connection is successfully established.
| response | The HTTP response that confirms the WebSocket upgrade. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
Reimplemented in XmobiTea.ProtonNet.Client.Socket.Clients.SocketWsClient.
|
virtual |
Prepares the WebSocket connection by setting the necessary headers.
| request | The HTTP request being sent to initiate the WebSocket connection. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
OnWsConnecting.
| request | The HTTP request that initiated the WebSocket connection. |
| response | The HTTP response that initiated the WebSocket connection. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
Called when the WebSocket connection is successfully disconnected.
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
Called when the WebSocket connection is in the process of disconnecting.
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
Handles a WebSocket error by reporting it to the client.
| error | The socket error. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
Handles a WebSocket error by reporting it to the client.
| error | The error message. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
Handles a ping frame received from the server by sending a pong frame.
| buffer | The buffer containing the ping frame. |
| position | The starting position in the buffer. |
| length | The length of the ping frame. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
Handles a pong frame received from the server.
| buffer | The buffer containing the pong frame. |
| position | The starting position in the buffer. |
| length | The length of the pong frame. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
|
virtual |
Processes the WebSocket frames received from the server.
| buffer | The buffer containing the received data. |
| position | The starting position in the buffer. |
| length | The length of the received data. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
Reimplemented in XmobiTea.ProtonNet.Client.Socket.Clients.SocketWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendBinary | ( | byte[] | buffer | ) |
Sends a binary message synchronously to the server.
| buffer | The byte array containing the binary message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendBinary | ( | byte[] | buffer, |
| int | position, | ||
| int | length ) |
Sends a binary message synchronously to the server.
| buffer | The byte array containing the binary message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendBinaryAsync | ( | byte[] | buffer | ) |
Sends a binary message asynchronously to the server.
| buffer | The byte array containing the binary message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendBinaryAsync | ( | byte[] | buffer, |
| int | position, | ||
| int | length ) |
Sends a binary message asynchronously to the server.
| buffer | The byte array containing the binary message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendClose | ( | int | status, |
| byte[] | buffer ) |
Sends a close frame with a status code synchronously to the server.
| status | The close status code. |
| buffer | The byte array containing the close message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendClose | ( | int | status, |
| byte[] | buffer, | ||
| int | position, | ||
| int | length ) |
Sends a close frame with a status code synchronously to the server.
| status | The close status code. |
| buffer | The byte array containing the close message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendCloseAsync | ( | int | status, |
| byte[] | buffer ) |
Sends a close frame with a status code asynchronously to the server.
| status | The close status code. |
| buffer | The byte array containing the close message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendCloseAsync | ( | int | status, |
| byte[] | buffer, | ||
| int | position, | ||
| int | length ) |
Sends a close frame with a status code asynchronously to the server.
| status | The close status code. |
| buffer | The byte array containing the close message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendPing | ( | byte[] | buffer | ) |
Sends a ping frame synchronously to the server.
| buffer | The byte array containing the ping message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendPing | ( | byte[] | buffer, |
| int | position, | ||
| int | length ) |
Sends a ping frame synchronously to the server.
| buffer | The byte array containing the ping message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendPingAsync | ( | byte[] | buffer | ) |
Sends a ping frame asynchronously to the server.
| buffer | The byte array containing the ping message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendPingAsync | ( | byte[] | buffer, |
| int | position, | ||
| int | length ) |
Sends a ping frame asynchronously to the server.
| buffer | The byte array containing the ping message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendPong | ( | byte[] | buffer | ) |
Sends a pong frame synchronously to the server.
| buffer | The byte array containing the pong message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendPong | ( | byte[] | buffer, |
| int | position, | ||
| int | length ) |
Sends a pong frame synchronously to the server.
| buffer | The byte array containing the pong message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendPongAsync | ( | byte[] | buffer | ) |
Sends a pong frame asynchronously to the server.
| buffer | The byte array containing the pong message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendPongAsync | ( | byte[] | buffer, |
| int | position, | ||
| int | length ) |
Sends a pong frame asynchronously to the server.
| buffer | The byte array containing the pong message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendText | ( | byte[] | buffer | ) |
Sends a text message synchronously to the server.
| buffer | The byte array containing the text message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| int XmobiTea.ProtonNetClient.WsClient.SendText | ( | byte[] | buffer, |
| int | position, | ||
| int | length ) |
Sends a text message synchronously to the server.
| buffer | The byte array containing the text message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendTextAsync | ( | byte[] | buffer | ) |
Sends a text message asynchronously to the server.
| buffer | The byte array containing the text message. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| bool XmobiTea.ProtonNetClient.WsClient.SendTextAsync | ( | byte[] | buffer, |
| int | position, | ||
| int | length ) |
Sends a text message asynchronously to the server.
| buffer | The byte array containing the text message. |
| position | The starting position in the buffer. |
| length | The number of bytes to send. |
Implements XmobiTea.ProtonNetClient.IWsClient.
| void XmobiTea.ProtonNetClient.WsClient.SendUpgrade | ( | HttpResponse | response | ) |
Upgrades the HTTP connection to a WebSocket connection.
| response | The HTTP response confirming the upgrade. |
Implements XmobiTea.ProtonNetCommon.IWebSocket.
